Trakz Tub Slider System

Trakz Tub Slider System

Designed and manufactured to the highest standards of the discerning healthcare professional, the Trakz Tub Slider System by RAZ consists of a mobility base, a tub base, and a bridge. This system allows the user to be showered over an existing bathtub when a roll-in shower is not available.

The Trakz-AP (Attendant Propel – non-tilting)

Features


  • Patented Zbrilok safety latch system to prevent the seat and user from moving onto the bridge unless the bridge is securely latched to both the tub base and the mobility base
  • Toolless height adjustment of both bases to facilitate set-up
  • Toolless horizontal stabilizer adjustments on the tub base simplify alignment and leveling thereby reducing set-up time significantly
  • Seven off-the-shelf bridge lengths plus custom lengths for optimal fit within the bathroom
  • Wraparound, swing-away arm supports, which can be removed to reduce the overall width of the mobile base to 20.75”
  • Dual-locking, Tente casters

Fit is everything

The way a product feels, fits, and moves is at the heart of how well it will suit you, and your daily life.

That’s why we offer clients the opportunity to visit our locations and get a true sense of any given product. Motion isn’t a place. It’s a partnership, and a promise: we work with you to turn our products into possibilities.

Product Specifications
Weight capacity 352 lbs (160 kg)
Overall width 23" (58.5cm) – with arm supports, 20.75" (53cm) – with arm supports removed
Back support height 20" (51cm)
Bridge length 7", 8.5", 9.5", 10.5", 12.5", 14.5", 16.5" + custom lengths
Underside of bridge to floor 15.75"- 19.75" (40-50cm) in 1" (2.5cm) incr. – base configuration – high range, 11.75"-15.75" (30-40cm) in 1" (2.5cm) incr. – base configuration – low range
Seat width 18" (46cm)
Seat depth 17" (43cm)
Clearance height under seat 16.25"-20.25" (41-51.5cm) in 1" (2.5cm) incr.*
Armrest height above seat 10" (25cm)
Product weight 77.5 lbs (35kg) - Trakz-AP, 95 lbs (43kg) - Trakz-AT
Manufacturer Details
RAZ
